Measuring Python Cohesion with Cohesion

How to measure cohesion in Python

What is Cohesion?

Cohesion is a software metric that measures the proximity of related methods and variables.

For example, in LCOM4, the functions accessing a variable in a class are traced and clustered. If the number of clusters is 1, the class is in a good state. If the number is 2 or more, the class is in a bad state because it should be split up. 0 (no method) is also a bad state.

This time, I found cohesion, which can measure cohesion in Python, and I will try it out.

The definition of cohesion in library cohesion seems to be 100% if a method uses all instance and class variables in a certain class.

Environment Building

I want to evaluate this against a real code base, so I bring the code for Zulip, a chat service made in Python.

Looking at the dependencies, it seems to use both Django and Tornado. Complicated.

$ git clone --depth 1 git@github.com:zulip/zulip.git
# 1e0339c18bb46a1c502b01a71c2d66471848cf36

Install cohesion

$ python -m pip install cohesion
$ python -m cohesion -h
usage: __main__.py [-h] [-v | -x] (-f FILES [FILES ...] | -d DIRECTORY) [-b BELOW | -a ABOVE]

        A tool for measuring Python class cohesion.


optional arguments:
  -h, --help            show this help message and exit
  -v, --verbose         print more verbose output
  -x, --debug           print debugging output
  -f FILES [FILES ...], --files FILES [FILES ...]
                        analyze these Python files
  -d DIRECTORY, --directory DIRECTORY
                        recursively analyze this directory of Python files
  -b BELOW, --below BELOW
                        only show results with this percentage or lower
  -a ABOVE, --above ABOVE
                        only show results with this percentage or higher

Putting cohesion on Zulip

I'm applying cohesion to Zulip.

Django is MTC, not MVC. The rule is roughly MVC Model = Django Model, MVC View = Django Template, MVC Controller = Django View.

I guessed that the calculation is likely to be in model and view. So I'm going to try to apply cohesion to one file.

$ python -m cohesion -f zerver/models/alert_words.py
File: zerver/models/alert_words.py
  Class: AlertWord (14:0)
    Total: 0.0%
  Class: Meta (24:4)
    Total: 0.0%

$ python -m cohesion -f zerver/views/auth.py
File: zerver/views/auth.py
  Class: TwoFactorLoginView (794:0)
    Function: __init__ 1/3 33.33%
    Function: get_context_data 2/3 66.67%
    Function: done 0/3 0.00%
    Total: 33.33%

Per definition, methods with double underscores are also target.

I can still accept __init__, but there are cases where __str__ appears. I feel it is noise to include it as a factor in the measure of good class design.

Batch measurement by specifying a directory

Next, use -d to apply cohesion to a directoriy.

$ python -m cohesion -d zerver/models/
File: zerver/models/custom_profile_fields.py
  Class: CustomProfileField (59:0)
    Function: __str__ 4/20 20.00%
    Function: as_dict 7/20 35.00%
    Function: is_renderable 1/20 5.00%
    Total: 20.0%
  Class: CustomProfileFieldValue (182:0)
    Function: __str__ 3/4 75.00%
    Total: 75.0%
  Class: Meta (188:4)
    Total: 0.0%
File: zerver/models/linkifiers.py
  Class: RealmFilter (48:0)
    Function: __str__ 3/4 75.00%
    Function: clean 2/4 50.00%
    Total: 62.5%
  Class: Meta (60:4)
    Total: 0.0%
File: zerver/models/onboarding_steps.py
  Class: OnboardingStep (8:0)
    Total: 0.0%
  Class: Meta (13:4)
    Total: 0.0%
(後略)

$ python -m cohesion -d zerver/views
File: zerver/views/registration.py
File: zerver/views/user_settings.py
File: zerver/views/digest.py
File: zerver/views/auth.py
  Class: TwoFactorLoginView (794:0)
    Function: __init__ 1/3 33.33%
    Function: get_context_data 2/3 66.67%
    Function: done 0/3 0.00%
    Total: 33.33%
File: zerver/views/custom_profile_fields.py
File: zerver/views/realm_linkifiers.py
File: zerver/views/documentation.py
  Class: DocumentationArticle (35:0)
    Total: 0.0%
  Class: ApiURLView (66:0)
    Function: get_context_data 1/1 100.00%
    Total: 100.0%
  Class: MarkdownDirectoryView (78:0)
    Function: get_path 4/5 80.00%
    Function: get_context_data 4/5 80.00%
    Function: get 2/5 40.00%
    Total: 66.67%
  Class: IntegrationView (323:0)
    Function: get_context_data 1/2 50.00%
    Total: 50.0%
(後略)

I tried to include a separate directory called actions, but overall there are a lot of files without classes.

Code quality metrics are often based on a Java-derived class-based philosophy, but I can't divert if the architecture doesn't use many classes.

Identification of upper and lower level files

You can use -b to bring up files below a certain level and -a to bring up files above a certain level.

As mentioned above, files without classes are much noisier. So I filter them appropriately.

$ python -m cohesion -d zerver/views -b 30 |grep -v 'File:'
  Class: DocumentationArticle (35:0)
    Total: 0.0%
  Class: VideoCallSession (39:0)
    Function: __init__ 0/0 0.00%
    Total: 0.0%
  Class: InvalidZoomTokenError (44:0)
    Function: __init__ 0/1 0.00%
    Total: 0.0%
  Class: InvalidMirrorInputError (29:0)
    Total: 0.0%
  Class: SentryTunnelSession (25:0)
    Function: __init__ 0/0 0.00%
    Total: 0.0%

$ python -m cohesion -d zerver/views -a 70 |grep -v 'File:'
  Class: ApiURLView (66:0)
    Function: get_context_data 1/1 100.00%
    Total: 100.0%
